Ricoh SP 4520DN - Drawing Order Summary

Offset Range Meaning Error Code
12-15 X'0000' or
X'FF00'
Printer Default (Black)
X'0001' or
X'FF01'
Blue
X'0002' or
X'FF02'
Red
X'0003' or
X'FF03'
Pink
X'0004' or
X'FF04'
Green
X'0005' or
X'FF05'
Turquoise
X'0006' or
X'FF06'
Yellow
X'0007' White - Color of Medium (Reset)
X'0008' Black
X'0010' Brown
X'FF07' Printer Default (Black)
X'FF08' Color of Medium (Reset)
Drawing Order Summary
Zero or more drawing orders follow each Begin Segment Introducer. These drawing orders either
specify graphics to be printed or assign drawing attributes.
Given below is a list of the supported drawing orders. Please refer to the AFP GOCA Reference,
S544-5498, for complete descriptions of all GOCA drawing orders.
Code Drawing Order
X'68' Begin Area
X'D1' Begin Image
5. Graphics Command Set
168
