Ricoh SP 4520DN - Resource ID Example with RIDF = Object-OID; Resource ID Example with RIDF = Data-Object Font

Offset Range Meaning Error Code
26-27 VERTICAL SCALE FACTOR
X'0000' No value supplied
X'0001' -
X'7FFF'
VSF in 1440th of an inch
28-29 HORIZONTAL SCALE FACTOR
X'0000' No value supplied
X'0001' -
X'7FFF'
HSF in 1440th of an inch
Resource ID example with RIDF = Object-OID
Offset Range Meaning Error Code
12 IDENTIFIER
X'06' Short Form OID
13 OID LENGTH
X'00' -
X'7F'
2 to end Unique OID
Any Value
Resource ID example with RIDF = Data-object font
Offset Range Meaning Error Code
12-13 Base Font HAID
X'0001' -
X'7EFF'
TrueType/OpenType font or
TrueType/OpenType collection
1. Device Control Command Set
20
