Bar Code Output Control
Offset Range Meaning Error Code
0-1 X'0010'-
X'xxxx'
LENGTH of Bar Code Output Control (BCOC) X'0202..0
5'
2-3 X'A66B' STRUCTURED FIELD ID X'020B..
05'
4 UNIT BASE (Measurement Units) X'0205..0
5'
X'00' 10 Inches
X'01' 10 Centimeters
5-6 X'0001' -
X'7FFF'
L-Units per UNIT BASE X'0206..0
5'
7-8 X'0001' -
X'7FFF'
X EXTENT of Bar Code BLOCK in L-units
See "Notation Conventions", IPDS Technical Reference 1.
X'0207..0
5'
X'FFFF' Use Load Page Descriptor Value
9-10 X'0001' -
X'7FFF'
Y EXTENT of Bar Code BLOCK in L-units
See "Notation Conventions", IPDS Technical Reference 1.
X'0207..0
5'
X'FFFF' Use Load Page Descriptor Value
11 X'30' MAPPING CONTROL OPTION (Position) X'0208..0
5'
12-13 X'8000' -
X'7FFF'
X OFFSET L-units See
See "Notation Conventions", IPDS Technical Reference 1.
X'0209..0
5'
14-15 X'8000' -
X'7FFF'
Y OFFSET L-units
See "Notation Conventions", IPDS Technical Reference 1.
X'0209..0
5'
Write Bar Code Control
