Page #471 background imageLoading...
Page #471 background image
3. Select the printer driver you want to use, and then click [Next].
4. Select [Specify a new port], and then click [Next].
5. Select [Network Printer], and then click [Next].
6. Double-click the name of the NetWare file server on the network tree.
The created queue is displayed.
7. Select the print queue, and then click [OK].
8. Check that the port of the selected printer is displayed in [Port :].
9. Click [Continue].
The installation starts.
10. Click [Finish] in the [Select Program] dialog box.
11. After the installation is complete, select one of the options to restart the computer either
now or later, and then click [Finish].
Restart the computer to complete installation.
12. After restarting the computer, on the [Start] menu, select [Printers and Faxes].
13. Right-click the printer's icon, and then click [Properties].
14. Click the [NetWare Settings] tab.
15. Clear the [Form Feed] and [Enable Banner] check boxes.
Do not change the check box settings that are automatically configured by the printer driver. If you
change the settings, the printer may not print correctly.
16. Click [OK].
NetWare is disabled as default. Enable the protocol using the control panel or Web Image
Monitor.
Notes When Using NetWare
Form Feed
Do not use NetWare to configure form feed. Form feed is controlled by the printer driver on
Windows. If NetWare form feed is configured, the printer may not print properly.
Disable form feed by clearing the [Form feed] check box on the [NetWare Settings] tab in the
printer properties dialog box.
Banner Page
Do not use NetWare to create a banner page.
Disable banner page settings by clearing the [Enable banner] check box on the [NetWare
Settings] tab in the printer properties dialog box.
Using as a Network Printer
21

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP 4520DN and is the answer not in the manual?

Ricoh SP 4520DN Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLED
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)5 s
Print speed (black, normal quality, A4/US Letter)40 ppm
Product colorWhite
Display diagonal4.3 \
Maximum duty cycle150000 pages per month
Number of print cartridges-
Page description languagesPCL 5e, PCL 6, PostScript 3
Total input capacity600 sheets
Total output capacity250 sheets
Maximum input capacity1600 sheets
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1110 W
Power consumption (off)0.58 W
Power consumption (printing)1740 W
Internal memory512 MB
Processor frequency533 MHz
Compatible memory cardsSD
Maximum internal memory1024 MB
Other operating systems supportedNovell NetWare 6.x
Server operating systems supportedWindows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper tray media typesEnvelopes, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight52 - 162 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
Weight and Dimensions IconWeight and Dimensions
Depth392 mm
Width370 mm
Height306 mm
Weight14000 g
