Setting Authentication Only
Authentication and Low
Level Encryption
Authentication and High
Level Encryption
Phase 2
Authentication
Algorithm
HMAC-
SHA512-256/
HMAC-
SHA384-192/
HMAC-
SHA256-128/
HMAC-SHA1-96
HMAC-
SHA512-256/
HMAC-
SHA384-192/
HMAC-
SHA256-128/
HMAC-SHA1-96
HMAC-SHA512-256/
HMAC-SHA384-192/
HMAC-SHA256-128
Phase 2 Encryption
Algorithm
Permissions
Cleartext (NULL
encryption)
3DES/AES-128/
AES-192/AES-256
AES-128/AES-192/
AES-256
Phase 2 PFS Inactive Inactive 2
Encryption key auto exchange settings items
When you specify a security level, the corresponding security settings are automatically
configured, but other settings, such as address type, local address, and remote address must still be
configured manually.
After you specify a security level, you can still make changes to the auto configured settings. When
you change an auto configured setting, the security level switches automatically to "User Setting".
Setting Description Setting value
Address Type
Specify the address type for which
IPsec transmission is used.
• Inactive
•
IPv4
• IPv6
Local Address
Specify the printer's address. If you
are using multiple addresses in
IPv6, you can also specify an
address range.
The printer's IPv4 or IPv6 address.
If you are not setting an address
range, enter 32 after an IPv4
address, or enter 128 after an IPv6
address.
Remote Address
Specify the address of the IPsec
transmission partner. You can also
specify an address range.
The IPsec transmission partner's
IPv4 or IPv6 address.
If you are not setting an address
range, enter 32 after an IPv4
address, or enter 128 after an IPv6
address.
Configuring IPsec
131
