Page #80 background image
Message Cause Solution
"Standard Tray is full. Remove the
paper."
The standard tray is full. Remove the paper.
"Supply order has failed." The automatic supply order
failed.
The message indicates the
printer tried to order the
supplies.
"This NetBIOS name is already in use.
(108/208)"
The NetBIOS name specified
for the printer is already used
by another device on the
network.
Contact your network
administrator.
"The same IPv4 Address already
exists.(102/202)"
The IPv4 address specified
for the printer is already used
by another device on the
network.
Contact your network
administrator.
"The selected job has already been
printed or deleted."
This message might appear if
you print or delete a job from
Web Image Monitor.
Press Exit on the message
screen.
"USB has a problem. Please call
service."
The printer has detected a
USB board failure.
Turn the printer off, and then
turn it on again. If the
problem persists, contact
your sales or service
representative.
"Values set for IPv6/Gateway
addresses are invalid.(110/210)"
The IPv6 address or gateway
address is invalid.
Check the network settings.
"Waste Toner almost full" The print cartridge must be
replaced when the life of the
waste toner is ending.
Prepare a new print
cartridge.
"Waste Toner full" The waste toner is full. For details, see "Replacing
the Print Cartridge",
Operating Instructions.
"WPA Auth. incomplete.(211)" WPA authentication could
not be completed.
Contact your network
administrator.
3. Troubleshooting
78

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP 4520DN and is the answer not in the manual?

Ricoh SP 4520DN Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLED
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)5 s
Print speed (black, normal quality, A4/US Letter)40 ppm
Product colorWhite
Display diagonal4.3 \
Maximum duty cycle150000 pages per month
Number of print cartridges-
Page description languagesPCL 5e, PCL 6, PostScript 3
Total input capacity600 sheets
Total output capacity250 sheets
Maximum input capacity1600 sheets
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1110 W
Power consumption (off)0.58 W
Power consumption (printing)1740 W
Internal memory512 MB
Processor frequency533 MHz
Compatible memory cardsSD
Maximum internal memory1024 MB
Other operating systems supportedNovell NetWare 6.x
Server operating systems supportedWindows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper tray media typesEnvelopes, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight52 - 162 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
Weight and Dimensions IconWeight and Dimensions
Depth392 mm
Width370 mm
Height306 mm
Weight14000 g
