Message Cause Solution
"No toner. Replace Toner
Cartridge."
The toner has run out. Replace
the print cartridge.
For details, see "Replacing the
Print Cartridge", Operating
Instructions.
"n ppr siz msmtch Select new
tray or use ppr size below."
("n" is a tray name.)
The size of the paper in the tray
does not match the paper size
specified in the printer driver.
Select a tray containing paper
that is the same size as the
specified paper size.
"Printer font error." An error has occurred in the font
settings.
Contact your service
representative.
"Problems with the wireless
board. Please call service."
(A "wireless LAN interface
board" is referred to as a
"wireless board".)
The printer has detected a
wireless LAN interface board
failure.
If the message appears again,
contact your service
representative.
"Remove the paper from
Standard Tray."
The standard tray is full. Remove the paper.
"Replacement of Drum Unit is
now necessary. Please call
service."
You need to replace the drum
unit.
Contact your sales or service
representative to obtain a new
unit.
"Replacement of Drum Unit will
soon be necessary. Please call
service."
You will need to replace the
drum unit soon.
Contact your sales or service
representative to obtain a new
unit.
"Replacement of Maintenance
Kit is now necessary. Please call
service."
You need to replace the
maintenance kit.
Contact your sales or service
representative to obtain a new
unit.
"Replacement of Maintenance
Kit will soon be
necessary.Please call service."
You will need to replace the
maintenance kit soon.
Contact your sales or service
representative to obtain a new
unit.
"The selected file(s) contained
file(s) without access privileges.
Only file(s) with access
privileges will be deleted."
You have tried to delete files
without the authority to do so.
To check your access
permission for stored
documents, or to delete a
document you do not have
permission to delete, see
Security Guide.
When Messages Are Displayed
81

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP 4520DN and is the answer not in the manual?

Ricoh SP 4520DN Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLED
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)5 s
Print speed (black, normal quality, A4/US Letter)40 ppm
Product colorWhite
Display diagonal4.3 \
Maximum duty cycle150000 pages per month
Number of print cartridges-
Page description languagesPCL 5e, PCL 6, PostScript 3
Total input capacity600 sheets
Total output capacity250 sheets
Maximum input capacity1600 sheets
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1110 W
Power consumption (off)0.58 W
Power consumption (printing)1740 W
Internal memory512 MB
Processor frequency533 MHz
Compatible memory cardsSD
Maximum internal memory1024 MB
Other operating systems supportedNovell NetWare 6.x
Server operating systems supportedWindows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper tray media typesEnvelopes, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight52 - 162 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
Weight and Dimensions IconWeight and Dimensions
Depth392 mm
Width370 mm
Height306 mm
Weight14000 g
