Offset Range Meaning Error Code
4-5 X'8000' -
X'7FFF'
LENGTH (Bl)
See "Notation Conventions", IPDS Technical Reference 1.
6-7 WIDTH (Bw)
X'8000' -
X'7FFF'
Printer Default 24/1440 inch
X'FFFF'
8 IGNORED
Draw I-Axis Rule
Draw I-axis Rule Control Sequence draws a rule in the i-direction.
Table 70. Draw I-Axis Rule
Offset Range Meaning Error Code
0-1 X'2BD3' TEXT CONTROL Escape Sequence
2 X'04' or
X'07'
LENGTH X'021E..
01'
3 DRAW I-AXIS RULE
X'E4' Unchained
X'E5' Chained
4-5 X'8000' -
X'7FFF'
LENGTH (Il)
See "Notation Conventions", IPDS Technical Reference 1.
6-7 WIDTH (Iw)
X'8000' -
X'7FFF'
Printer Default 24/1440 inch
X'FFFF'
8 IGNORED
Presentation Text Commands
111
