Offset Range Meaning Error Code
12-13 SCAN LINE DIRECTION X'0248..0
1'
X'0000' 0 degrees
X'2D00' 90 degrees
X'5A00 180 degrees
X'8700' 270 degrees
14-15 SCAN LINE SEQUENCE DIRECTION X'0249..0
1'
X'0000' 0 degrees
X'2D00' 90 degrees
X'5A00' 180 degrees
X'8700' 270 degrees
16 REFERENCE COORDINATE SYSTEM X'024A..
01'
X'00' Absolute I, Absolute B
X'20' Absolute I, Relative B
X'40' Relative I, Absolute B
X'60' Relative I, Relative B
X'A0' Xp, Yp
17-19 X'FF8000'
-
X'007FFF'
Xp, I or I offset coordinate of the IM image block origin X'024A..
01'
20 X'00' Reserved
21-23 X'FF8000'
-
X'007FFF'
Yp, B or B offset coordinate of the IM image block origin X'024A..
01'
Write Image Control
131
