Offset Range Meaning Error Code
1 X'02'-X'FF' LENGTH of the following bytes X'0500..0
3'
2 COMPRESSION ALGORITHM X'0595..1
0'
X'0595..1
1'
X'01' IBM MMR compression
X'03' No compression
X'06' RL4 compression
X'08' ABIC (Bilevel Q-Coder)
X'80' G3 MH (CCITT T.4 facsimile 1-D)
X'81' G3 MR (CCITT T.4 G3 facsimile 2-D)
X'82' G4 MMR (CCITT T.6 G4 facsimile 2-D)
3 RECORDING ALGORITHM X'0595..1
0'
X'01' RIDIC (Recording Image Data Inline Code) Unpadded RIDIC
4 BIT ORDER within each image data byte
X'00' Left-to-Right
X'01' Right-to-Left
Image Data Element Size Parameter
Offset Range Meaning Error Code
0 X'96' IMAGE DATA ELEMENT SIZE X'0596..0
F'
1 X'01'-X'FF' LENGTH of the following bytes X'0500..0
3'
4. IO Image Command Set
144
