Offset Range Meaning Error Code
2-3 X'A6BB' STRUCTURED FIELD ID X'020B..
05'
4 UNIT BASE (Measurement Units) X'0205..0
5'
X'00' 10 Inches
X'01' 10 Centimeters
5 X'00' Reserved
6-7 X'0001' -
X'7FFF'
Xg UNITS per UNIT BASE X'0206..0
5'
8-9 X'0001' -
X'7FFF'
Yg UNITS per UNIT BASE Yg = Xg X'0206..0
5'
10-13 X'000000
00'
Reserved
14-15 X'8000'-
X'7FFF'
Xg LEFT LIMIT of Graphic Presentation Space Window.
See "Notation Conventions", IPDS Technical Reference 1.
16-17 X'8000'-
X'7FFF'
Xg RIGHT LIMIT of Graphic Presentation Space Window.
See "Notation Conventions", IPDS Technical Reference 1.
18-19 X'8000'-
X'7FFF'
Yg TOP LIMIT of Graphic Presentation Space Window.
See "Notation Conventions", IPDS Technical Reference 1.
20-21 X'8000'-
X'7FFF'
Yg BOTTOM LIMIT of Graphic Presentation Space Window.
See "Notation Conventions", IPDS Technical Reference 1.
22-27 X'000000
000000'
Reserved
28-n INITIAL GRAPHICS DEFAULTS. See "GDD Initial Graphics
Defaults Self Describing Instructions"
If the image resolution specified in the GDD is X'0000' (indicating that no explicit resolution is specified),
then the resolution used is the resolution specified in the OPC's Image and Coded Font Resolution Self-
Defining Field.
Graphics Commands
151

Ricoh SP 4520DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Product color	White
Display diagonal	4.3 \
Maximum duty cycle	150000 pages per month
Number of print cartridges	-
Page description languages	PCL 5e, PCL 6, PostScript 3
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1600 sheets
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1110 W
Power consumption (off)	0.58 W
Power consumption (printing)	1740 W
Internal memory	512 MB
Processor frequency	533 MHz
Compatible memory cards	SD
Maximum internal memory	1024 MB
Other operating systems supported	Novell NetWare 6.x
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper tray media types	Envelopes, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	306 mm
Weight	14000 g
