6. Output tray for the ADF
Originals scanned with the ADF are output here.
7. Exposure glass
Place originals face down here.
8. Cover for the exposure glass
Open this cover to place originals on the exposure glass.
9. Stop fence
Raise the rear fence to prevent A4 or letter-size prints from falling behind the machine.
After using the stop fence, be sure to return it to its original position. The fence may be damaged if it is hit with
something or excessive force is applied.
10. Top cover open lever
Pull this lever upward to open the top cover.
11. Control panel
See page 28 "Guide to the Names and Functions of the Machine's Control Panel".
12. Ventilation holes
Prevent overheating.
13. Front cover open lever
Pull this lever to open the front cover.
14. Paper size dial
Use this dial to specify the paper size. To use a paper size that is not indicated on the paper size dial, set the
dial to " ". If this is the case, set the paper size using the control panel.
15. Paper tray (Tray 1)
Load paper here.
16. Remaining paper indicator
Indicates the approximate amount of paper remaining in the tray.
17. Main power switch
To operate the machine, the main power switch must be on. If it is off, turn the switch on.
18. Front cover
Open this cover when replacing the waste toner bottle, etc., or removing jammed paper. Pull the right side
lever to open the front cover.
19. Bypass tray
Use to copy or print on thick paper, envelopes, and label paper (adhesive labels).
20. Paper guides
When loading paper in the bypass tray, align the paper guides flush against the paper.
21. Extender for the bypass tray
Pull this extender out when loading A4 , 8
1
/
2
× 11 or larger size paper in the bypass tray.
Guide to Names and Functions of Components
23
