• Press Scale to set the vertical scale of the operation results. For setting methods,
refer to the descriptions in "
Parameter Setting Method
". You can also directly
rotate Wave Vertical SCALE or enable the touch screen to adjust the vertical
Scale.
• Press AutoSetting to adjust the vertical scale and offset of the operation results
to an optimal value based on the current configuration, so as to better observe.
• Press More > ωc1 to set the lower limit frequency. For setting methods, refer to
descriptions in "
Parameter Setting Method
".
•
Press More > ωc2 to set the upper limit frequency. For setting methods, refer to
descriptions in "
Parameter Setting Method
".
NOTE
The settable ranges of the Lower and Upper limit frequencies are related to the Math
sample rate (displayed at the bottom of the screen when the Math function is enabled).
The sample rate of the analog channel or the changes of the memory depth can affect
the Math sample rate.
• Press More > Invert to enable or disable the inverted display function of the
waveform.
• Press More > Label to set the label for math operation results. For details, refer
to the descriptions in "
Math Operation Label
".
• Press More > Color Grade to enable or disable the color grade display of the
operation results. When enabled, different colors are displayed on the screen to
indicate the times of data acquisition or acquisition probability.
• Press More > Reset ColorGrade to clear the color grade display and display the
color grade again.
9.1.21 AX+B
Applies a linear function to the selected source, and displays the results.
Press > Math1 > Operator to "AX+B":
Operations and Measurements
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
167
