For the key operation, you can directly press the front-panel keys (except the Power
key, key, and the key) to obtain the help information. For the knob operation,
you can rotate the knob or press down the knob to get the help information (except
the multifunction knob , Wave Vertical POSITION, and Wave Vertical
SCALE). As the function of rotating the knob is different from that of pressing down
the knob, these two operations will give you different help information.
Method 2:
In the "Help Options", rotate the multifunction knob
to switch among the help
options to get the corresponding help information.
Method 3:
Enable the touch screen and tap the desired help option to get the corresponding
help information.
TIP
• Help information for other keys and buttons:
- Power key: powers on/off the instrument.
- key: displays or hides menus. Pressing this key can hide the menus.
- key: returns to the previous menu or last set function menu.
- Multifunction knob : In non-menu-operation mode, rotate this knob to adjust
the brightness of waveform display. When you operate on the menu, the backlight
of the knob is illuminated. For the menu item that has multiple parameters under it,
when you press the menu softkey, rotate the knob to select the parameter item,
then press down the knob to select it (sometimes, the specified parameter item can
be selected by rotating the knob). The knob can also be used to modify parameters,
input the filename, etc.
- Wave Vertical
POSITION: Rotate the knob to adjust the vertical position of the
current digital channel waveform, the vertical position of the math operation
waveform, the vertical position of the reference waveform, or the vertical display
position of the bus decoding.
- Wave Vertical SCALE: Rotate the knob to adjust the vertical scale of math
operation waveform or the vertical scale of the reference waveform, and also can
adjust the size of the displayed digital channel waveforms.
• If the menu item is grayed out, you cannot press the corresponding front-panel menu
key to obtain the help information. What you can do is only to follow the above Method
2 or 3 to get the help information.
4.12 To View the Option and the Option Installation
This series of oscilloscope provides multiple options to fulfill your measurement
requirements. If you need any of these options, order them according to the Order
Quick Start
44
