Enable the touch screen and then tap this icon to enable the function navigation.
NOTE
In Slope Trigger, Runt Trigger, and Window trigger, you need to set the upper and lower limits
of the trigger level, and two trigger level labels ( and ) are displayed.
4.8 Touch Screen Controls
MSO8000 series provides a 10.1-inch super large capacitive touch screen, which
supports multi-touch and gesture operation. It has strong waveform display capability
and excellent user experience. It features great convenience, high flexibility, and great
sensitivity. The actions supported by the touch screen controls include tapping,
pinching & stretching, dragging, and rectangle drawing.
TIP
The touch screen function is available for all the menus displayed on the screen and the
buttons enabled. In this manual, key operation descriptions are illustrated in details, and as for
the touch screen function about some operations, refer to descriptions in relevant chapters.
4.8.1 Tap
Use one finger to touch the symbol or characters on the screen slightly, as shown in
Figure 4.16 . With the Tap gesture, you can perform the following operation:
• Tap the menu displayed on the screen to operate on the menu.
• Tap the function navigation icon at the lower-left corner of the touch screen
to open the function navigation.
• Tap the displayed numeric keypad to set the parameters.
• Tap the virtual keypad to set the label name and the filename.
• Tap the close button at the upper-right corner of the message box to close the
prompt window.
• Tap other windows on the touch screen and operate on the windows.
