MSO8000 Series Overview
MSO8000 series is a medium and high-end mixed signal digital oscilloscope designed
based on UltraVision II platform built on RIGOL's custom ASIC technology. Integrating
7 independent instruments into one, the oscilloscope is equipped with the analog
bandwidth of up to 2 GHz, extremely high memory depth of 500 Mpts, sound
waveform display effects, excellent waveform capture rate, and powerful data analysis
functions. Many of its specifications have reached the top level in the industry.
Meanwhile, it supports the real-time eye diagram measurement and jitter analysis. Its
cost-effective features and high performance make it prominent as the 2 GHz mixed
signal digital oscilloscope.
Main Features:
• Analog channel bandwidth: 600 MHz, 1 GHz, and 2 GHz
• 4 analog channels, 1 EXT channel, and 16 digital channels (standard, required to
purchase the probe)
• Up to 10 GSa/s real-time sample rate
• Up to 500 Mpts memory depth (standard)
• Waveform capture rate > 600,000 wfms/s
• Up to 450,000 frames of hardware real-time and ceaseless waveforms recording
and playback
• Integrates 7 independent instruments into 1, including digital oscilloscope, 16-
channel logic analyzer, spectrum analyzer, arbitrary waveform generator (option),
digital voltmeter, 6-digit frequency counter and totalizer, and protocol analyzer
(option)
• Provides auto measurement for up to 41 waveform parameters, offers full-
memory hardware measurement function
• Various math operations, built-in powerful FFT analysis and peak search
functions
• Histogram analysis (standard)
• Independent search, navigation key, and event table
• Real-time eye diagram and jitter analysis software (option)
