For each oscilloscope, the MAC address is unique. When assigning the IP address for
the oscilloscope, the system uses the MAC address to identify the instrument.
VISA Address
Displays the VISA address currently used by the oscilloscope.
Web Control Information
Displays the user name and password for network configuration of the oscilloscope
through the LXI webpage.
TIP
Connect the oscilloscope to the local area network. Start up Ultra Sigma, and then right-click
the resource name and select "LXI-Web" to load the LXI webpage. You can also directly input
the IP address of the oscilloscope in the address bar of the PC browser to load the LXI
webpage.
23.1.2 To Set mDNS
Press mDNS continuously to enable or disable the multicast Domain Name System
(mDNS). This system is used to provide the function of DNS server for service
discovery in a small network without a DNS server.
23.1.3 To Set the Host Name
Press Host Name to input the host name. For the host name input method, refer to
relevant descriptions in "
To Create a Folder
".
23.1.4 To Set the GPIB address
Before using the GPIB interface, use the USB-GPIB interface converter (an option that
requires to be ordered separately) to extend the GPIB interface, and then use the GPIB
cable to connect the instrument to the PC.
Press > IO > GPIB, then rotate the multifunction knob directly to set the
GPIB address or use the pop-up numeric keypad to input the GPIB address. Its
settable range is from 1 to 30. By default, it is 1.
23.1.5 To Set HDMI
Sets the status and parameters of the HDMI video output interface on the rear panel.
Note that only when the HDMI interface is available, can this menu be enabled.
Press HDMI to enter the HDMI setting menu.
• Press Output continuously to enable or disable the video output.
System Utility Function Setting
