26
Appendix
26.1 Appendix A: Options and Accessories
Order Information Order No.
Model
MSO8204 (2 GHz, 10 GSa/s, 500 Mpts, 4+16 CH MSO) MSO8204
MSO8104 (1 GHz, 10 GSa/s, 500 Mpts, 4+16 CH MSO) MSO8104
MSO8064 (600 MHz, 10 GSa/s, 500 Mpts, 4+16 CH MSO) MSO8064
Standard Accessories
USB Cable CB-USBA-USBB-FF-150
Passive HighZ Probe x4 (500 MHz) RP3500A
Passive Low-impedance Probe x2 (1.5 GHz, only for the
MSO8204/MSO8104)
RP6150A
Front Protective Cover MSO8000-FPC
Power Cord Conforming to the Standard of the Destination
Country
-
Recommended Accessories
16-channel Logic Analyzer Probe RPL2316
Active Single-ended/Differential Probe (2.5 GHz BW) PVA7250
Active Differential Probe (1.5 GHz BW) RP7150
Active Differential Probe (800 MHz BW) RP7080
Active Single-ended Probe (1.5 GHz BW) RP7150S
Active Single-ended Probe (800 MHz BW) RP7080S
Rack Mount Kit RM6041
Near-field Probe NFP-3
Power Analysis Phase Deviation Correction Jig RPA246
Digital Oscilloscope Demonstration Plate DK-DS6000
USB-GPIB Adaptor USB-GPIB
Bandwidth Upgrade Option
Bandwidth Upgrades from 600 MHz to 1 GHz MSO8000-BW6T10
Bandwidth Upgrades from 600 GHz to 2 GHz MSO8000-BW6T20
Bandwidth Upgrades from 1 GHz to 2 GHz MSO8000-BW10T20
Bundle Option
Function and application bundle option, including
MSO8000-COMP, MSO8000-EMBD, MSO8000-AUTO,
MSO8000-FLEX, MSO8000-AUDIO, MSO8000-AERO,
MSO8000-AWG, MSO8000-JITTER and MSO8000-PWR
MSO8000-BND
Serial Protocol Analysis Option
PC Serial Bus Trigger and Analysis (RS232/UART) MSO8000-COMP
Embedded Serial Bus Trigger and Analysis (I2C, SPI) MSO8000-EMBD
Auto Serial Bus Trigger and Analysis (CAN, CAN-FD, LIN) MSO8000-AUTO
Appendix
384
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
