Rigol MSO8000-BND - Exp.rise; Figure 21.3 Sinc; Figure 21.4 Exp.rise

Figure 21.3 Sinc
21.1.8 Exp.Rise
Press Wave, then use the multifunction knob to select "Exp.Rise" and then press
down the knob to select the waveform. You can also press Wave continuously or
enable the touch screen to select it. At this time, you can set the parameters for the
Exp.Rise waveform (as shown in the figure below). For setting methods, refer to
descriptions in " To Output Sine ".
Figure 21.4 Exp.Rise
Function/Arbitrary Waveform Generator (Option)
