4.2 Appearance and Dimensions
Figure 4.1 Front View
134.2mm
Figure 4.2 Vertical View
4.3 To Prepare for Use
4.3.1 To Adjust the Supporting Legs
Adjust the supporting legs properly to use them as stands to tilt the oscilloscope
upwards for stable placement of the oscilloscope as well as better operation and
observation. Users can also fold the supporting legs when the instrument is not in
use for easier storage or shipment, as shown in the figure below.
