press CLK continuously or enable the touch screen to select it. The analog
channel (CH1-CH4) or digital channel (D0-D15) can all be selected.
- When you select the analog channel (CH1-CH4), press Threshold below CLK,
then rotate the multifunction knob or use the numeric keypad to set the
threshold of the clock channel.
- Press Slope to set the instrument to sample MISO and MOSI on the rising
edge ( ) or the falling edge ( ) of CLK.
- Set MISO and MOSI
- Press MISO, then rotate the multifunction knob to select the MISO data
channel, and then press down the knob to select it. You can also press MISO
continuously or enable the touch screen to select it. The available channels
include OFF, analog channels (CH1-CH4), and digital channels (D0-D15).
When you select the analog channel (CH1-CH4), press Threshold below
MISO, then rotate the multifunction knob or use the numeric keypad to
set the threshold of the MISO data channel.
- Press
MOSI, then rotate the multifunction knob to select the MOSI data
channel, and then press down the knob to select it. You can also press MOSI
continuously or enable the touch screen to select it. The available channels
include OFF, analog channels (CH1-CH4), and digital channels (D0-D15).
When you select the analog channel (CH1-CH4), press Threshold below
MOSI, then rotate the multifunction knob or use the numeric keypad to
set the threshold of the MOSI data channel.
NOTE
The source channels of MISO and MOSI cannot be set to "OFF" at the same time.
5. Set the Data Parameters
Press
Settings to enter the data setting menu.
- Set the endian
Press Endian to select "LSB" or "MSB". By default, it is MSB
Protocol Decoding
250
