keypad to set the SCLK threshold. When you modify the threshold of the
clock channel, a dotted line displaying the current threshold level is
displayed on the screen. It disappears in about 2 s after you stop modifying
the threshold.
- Press SCLK Edge continuously to select "Rising( )" or "Falling( )" as the
desired clock edge.
- Set the WS source and the threshold
- Press WS, and rotate the multifunction knob to select the desired
channel, and then press down the knob to select it. You can also press WS
continuously or enable the touch screen to select it. You can select CH1-CH4
or D0-D15.
- When you select the analog channel (CH1-CH4), press WS Thre below WS,
then rotate the multifunction knob or use the pop-up numeric keypad to
set the threshold of the WS signal. When you modify the WS threshold, a
dotted line displaying the current threshold level is displayed on the screen.
It disappears in about 2 s after you stop modifying the threshold.
- Set the data channel source and the threshold
- Press Data, then rotate the multifunction knob to select the desired data
channel source, and then press down the knob to select it. You can also press
Data continuously or enable the touch screen to select it. You can select
CH1-CH4 or D0-D15.
- When you select the analog channel (CH1-CH4), press Data Thre below
Data, then rotate the multifunction knob or use the pop-up numeric
keypad to set the threshold of the data signal. When you modify the data
threshold, a dotted line displaying the current threshold level is displayed on
the screen. It disappears in about 2 s after you stop modifying the threshold.
4. Set the Bus Parameters
Press
Settings to enter the bus setting menu.
Protocol Decoding
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
271
