Press Cycles, then rotate the multifunction knob or use the pop-up numeric
keypad to set the cycle count. For the Infinite burst type, the Cycles menu is
disabled and grayed out.
3. Set the Burst Delay
Burst delay indicates the time from when receiving the trigger signal to starting to
output N Cycle of bursts or Infinite burst.
Press Delay, then rotate the multifunction knob or use the pop-up numeric
keypad to set the burst delay. The setting range of the delay time is related to the
burst cycle count.
4. Burst Setting
Press Settings to enter the burst setting menu.
- Set the trigger source
The trigger sources of the burst can be Internal or Manual. The generator will
generate a burst output when a trigger signal is received, and then it waits for
the next trigger signal.
Press
Trig Source and rotate the multifunction knob to select the desired
trigger source, and then press down the knob to select it. You can also press
Trig Source continuously or enable the touch screen to select it. The available
trigger sources include Internal and Manual. For the Infinite burst type, the Trig
Source menu is disabled and grayed out. You can only perform the manual
trigger.
- Internal: The Function/Arbitrary Waveform Generator outputs continuous N
cycle.
- Manual: when you press Manual Trig one time, one burst output is
immediately launched for the corresponding channel. For the Infinite burst
type, the Cycles menu is disabled and grayed out.
- Set the burst period
It is defined as the time from the beginning of one burst to that of another
burst.
Press
Burst Period, then rotate the multifunction knob or use the pop-up
numeric keypad to set the burst period. The setting range is from 2 ms to 500 s.
By default, it is 10 ms.
Function/Arbitrary Waveform Generator (Option)
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
321
