Parameter Factory Settings
Avg Number 2
Offset 0 V
Scale 500 mV
Invert Off
Logic Analyzer (LA)
Select None
D7-D0 Off
D15-D8 Off
Wave Size Medium
Arrange D15-D0
Threshold
D7-D0 1.4 V
D15-D8 1.4 V
Label
Display Off
Select D0
Label D0
Decode
Bus Type Parallel
Bus Status Off
Format Hex
Label On
Event Table Off
Store and Load
