2-47
Copying Functions
2
ComColor Series User’s Guide 09
■ Binding side
Select the binding side of the paper.
[Left], [Right], [Upper]
■ Punch
Specify the number of holes to be punched.
[OFF], [2 holes], [3 holes], [4 holes]
1
Display the [Staple/Punch] screen.
Follow Steps 1 and 2 in "Configuring the Staple Setting".
2
Select the original orientation.
3
Select the binding side.
4
Configure the punch setting.
5
Press [OK].
The settings are confirmed and the previous
screen is displayed.
● Specifying the binding margin
You can specify the binding margin so that staples
and punch holes are not in the printing area.
Specify the binding margin between 0 mm and 50
mm (1 15/16") (in 1 mm units).
1
Display the [Staple/Punch] screen.
Follow Steps 1 and 2 in "Configuring the Staple
Setting".
2
Specify the binding margin.
• Press the input box and enter the number using
[S] and [T] or the numeric keys.
• To clear the fields, press the [Clear] key.
• If part of the printing area is missing due to the
binding margin setting, press [Auto reduce].
3
Press [OK].
The settings are confirmed and the previous
screen is displayed.
Paper folding
Select this when folding paper in two.
● The multifunction finisher is required to use this
function.
● You cannot use "2-fold" and "Staple/Punch" at
the same time.
<Size of paper that can be folded>
• A3, B4, A4, Ledger, Legal, Letter, Foolscap and
custom size
*
*
The administrator must register the paper size
in advance. Ask your administrator.
• Paper weight: 60 g/m
2
(16-lb bond) to 90 g/m
2
(24-lb bond)
■ Original orientation
[Top side up]
Select this when loading originals in an orientation
from which they can be read normally.
[Top side left]
Select this when loading originals so that the top of
the original is aligned with the left edge.
■ Paper folding type
[OFF], [2-fold]
210 mm - 330 mm
(8 1/4" - 13")
280 mm - 457 mm
(11" - 18")
Paper feed and
output direction
2-fold
