Preface
Additional Resources
These documents contain additional information concerning related products
from Rockwell Automation.
Table 1 - Additional Resources
Resource Description
FLEX 5000 I/O Modules Specifications Technical Data,
publication 5094-TD001
Provides specifications for FLEX 5000 EtherNet/IP
adapters and FLEX 5000 modules.
FLEX 5000 EtherNet/IP Adapters with RJ45 Ports
Installation Instructions, publication 5094-IN001
Describes how to install and wire the 5094-AENTR,
5094-AENTRXT, 5094-AEN2TR, and 5094-AEN2TRXT
EtherNet/IP adapters.
FLEX 5000 EtherNet/IP Adapters with SFP Support
Installation Instructions, publication 5094-IN002
Describes how to install and wire the 5094-AENSFPRXT
and 5094-AEN2SFPRXT EtherNet/IP adapters.
FLEX 5000 Digital 16-point Sinking Input Modules
Installation Instructions, publication 5094-IN003
Describes how to install and wire the 5094-IB16 and
5094-IB16XT digital input modules.
FLEX 5000 Digital 16-point Sourcing Output Modules
Installation Instructions, publication 5094-IN004
Describes how to install and wire the 5094-OB16 and
5094-OB16XT digital output modules.
FLEX 5000 Digital 8-point Isolated Relay Output Modules
Installation Instructions, publication 5094-IN005
Describes how to install and wire the 5094-OW8I and
5094-OW8IXT digital output modules.
FLEX 5000 Analog 8-channel Current/Voltage Input
Modules Installation Instructions, publication
5094-IN006
Describes how to install and wire the 5094-IF8 and
5094-IF8XT analog input modules.
FLEX 5000 Analog 8-channel Current/Voltage Output
Modules Installation Instructions, publication
5094-IN007
Describes how to install and wire the 5094-OF8 and
5094-OF8XT analog output modules.
FLEX 5000 Analog 8-channel Current/Voltage/RTD/
Thermocouple Input Modules Installation Instructions,
publication 5094-IN008
Describes how to install and wire the 5094-IY8 and
5094-IY8XT analog input modules.
FLEX 5000 High-speed Counter I/O Modules Installation
Instructions, publication 5094-IN009
Describes how to install and wire the 5094-HSC and
5094-HSCXT high-speed counter I/O modules.
FLEX 5000 Terminal Base Assembly Modules Installation
Instructions, publication 5094-IN010
Describes how to install and wire the terminal base
assemblies for the FLEX 5000 system.
FLEX 5000 Digital 16-point Sinking Safety Input
Modules Installation Instructions, publication
5094-IN012
Describes how to install and wire the 5094-IB16S and
5094-IB16SXT digital safety input modules.
FLEX 5000 Digital 16-point Sourcing Safety Output
Modules Installation Instructions, publication
5094-IN013
Describes how to install and wire the 5094-OB16S and
5094-OB16SXT digital safety output modules.
FLEX 5000 Analog I/O Modules User Manual, publication
5094-UM002
Describes how to configure, operate, and troubleshoot
FLEX 5000 analog I/O modules.
FLEX 5000 High-speed Counter I/O Modules User
Manual, publication 5094-UM003
Describes how to configure, operate, and troubleshoot
FLEX 5000 high-speed counter modules.
CompactLogix 5380 Controllers User Manual,
publication 5069-UM001
Describes how to configure, operate, and troubleshoot
CompactLogix™ 5380 controllers.
EtherNet/IP Communication Modules in 5000 Series
Control Systems User Manual, publication ENET-UM004
Describes how to configure, operate, and troubleshoot
the FLEX 5000 EtherNet/IP adapters.
Integrated Architecture and CIP Sync Configuration
Application Technique, publication IA-AT003
Provides information about CIP Sync technology and
how to synchronize clocks within the Rockwell
Automation Integrated Architecture® system.
Electronic Keying in Logix5000 Control Systems
Application Technique, publication LOGIX-AT001
Describes how to use electronic keying in Logix 5000
control system applications.
Logix5000 Controllers Tasks, Programs, and Routines
Programming Manual, publication 1756-PM005
Provides more information on event tasks and event
task configuration.
Position-based Output Control with the MAOC
Instruction, publication 1756-AT017
Describes how to configure time-scheduled output
control with the MAOC instruction.
