Appendix D Safety Data for I/O Modules
FLEX 5000 I/O Safety Input
Module Safety Data
Tabl e 43 lists the safety data for the 5094-IB16S and 5094-IB16SXT modules.
FLEX 5000 I/O Safety
Output Module Safety Data
Tabl e 44 lists the safety data for the 5094-OB16S and 5094-OB16SXT modules.
Table 43 - 5094-IB16S and 5094-IB16SXT Module Safety Parameter Data
Attribute Point Operation Type
Single Channel Dual Channel
(at Controller Instruction)
Total Failure Rate (λ (safety related)) 1.246E-06 1.397E-06
Safe Failure Fraction (SFF) 99.969% 99.967%
Safe Failure Rate (λS) 7.97E-07 8.63E-07
Diagnostic Coverage (DC) 99.867% 99.913%
Dangerous Failure Rate (λD) 4.4950E-07 5.3402E-07
Dangerous Detected Failure Rate (λDD) 4.4890E-07 5.3356E-07
Dangerous Undetected Failure Rate (λDU) 3.81E-10 4.6619E-10
Diagnostic Test Interval (hours) 4 4
Hardware Fault Tolerance (HFT) 0 1
Spurious Trip Rate (STR) 5.40 E-06 —
Mean Time to Failure, Spurious (MTTF-spurious), (hours) 185068 —
PFH (1/hours) 3.81E-10 4.6619E-10
PFD
AVE
, at Mission Time of 20 years 3.34E-05 4.08E-05
Safety Reaction Time (SRT), (millisecond) 6 6
Table 44 - 5094-OB16S and 5094-OB16SXT Module Safety Parameter Data
Attribute Point Operation Type
Single Channel Dual Channel
Total Failure Rate (λ (safety related)) 2.0565E-06 2.5524E-06
Safe Failure Fraction (SFF) 99.977% 99.983%
Safe Failure Rate (λS) 1.3238E-06 1.5666E-06
Diagnostic Coverage (DC) 99.937% 99.956%
Dangerous Failure Rate (λD) 7.3278E-07 9.8585E-07
Dangerous Detected Failure Rate (λDD) 7.3232E-07 9.8541E-07
Dangerous Undetected Failure Rate (λDU) 4.6523E-10 4.3173E-10
Diagnostic Test Interval (hours) 4 4
Hardware Fault Tolerance (HFT) 0 1
Spurious Trip Rate (STR) 5.68E-06 —
Mean Time to Failure, Spurious (MTTF-spurious), (hours) 176037 —
PFH (1/hours) 4.6523E-10 4.3173E-10
PFD
AVE
, at Mission Time of 20 years 4.0754E-05 3.7819E-05
Safety Reaction Time (SRT), (millisecond) 4.5 4.5
