Rockwell Automation Allen-Bradley FLEX 5000 User Manual

Rockwell Automation Publication 5094-UM001C-EN-P - April 2019 57
Chapter 4
Output Module Features
This chapter describes features common to these FLEX 5000™ standard and
safety output modules:
• 16-point standard DC output module, catalog number 5094-OB16
• 16-point standard DC output module for extreme environments,
catalog number 5094-OB16XT
• 16-point safety DC output module, catalog number 5094-OB16S
• 16-point safety DC output module for extreme environments,
catalog number 5094-OB16SXT
• Standard relay output module, catalog number 5094-OW8I
• Standard relay output module for extreme environments,
catalog number 5094-OW8IXT
Features Specific to All
FLEX 5000 Output Modules
The following topics are specific to all FLEX 5000 output modules.
Output State Change Time
Tabl e 10 lists the time that it takes for FLEX 5000 output module outputs to
change state after a command.
Topic Page
Features Specific to All FLEX 5000 Output Modules 57
Features Specific to Only 5094-OB16 and 5094-OB16XT Modules 66
Feature Specific to Only 5094-OW8I and 5094-OW8IXT Modules 69
STATUS
POWER
SAFETY DIGITAL 16 INPUT 24 VDC
5094-IB16S
5
5
TB3I
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
STATUS
POWER
DIGITAL 16 INPUT 24 VDC
5094-IB16
1
1
TB3
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Safety Modules
Standard Modules
Table 10 - Time for a Module Output to Change States
Module Time
(1)
(1) The times that are listed in Tabl e 1 0 are from the time the module receives the message.
5094-OB16, 5094-OB16XT 100 μs
5094-OB16S, 5094-OB16SXT 4.5 ms
5094-OW8I, 5094-OW8IXT 10 ms
