Rockwell Automation Publication 5094-UM001C-EN-P - April 2019 151
Module Tag Definitions Appendix B
Output Tags
Tabl e 37 describes the 5094-OB16 module output tags.
Table 37 - 5094-OB16 Module Output Tags
Name Data Type Definition Valid Values
TimeBase LINT Indicates the TimeBase for all schedule times in a
scheduled output consumed assembly or point. The
TimeBase + The Schedule[n].TimeOffset determines the
time for the schedule. Base/Offset scheme that is used to
fit enough schedules into the assembly.
Any positive value.
Ptxx.Data BOOL Current digital input value. • 0 = Off
•1 = On
Ptxx.ScheduleEn BOOL Specifies the use of normal output data or scheduled data. • 0 = Normal output data
• 1 = Scheduled data
Schedulex SINT Indicates which schedule to load from 32 available
schedules.
• 1…32 = Valid schedule
• 0, 129…255 = No schedule
Schedulex.ID SINT There are 32 schedules available (for Neo R1 products).
Indicates which schedule to load.
• 1…32 = Valid schedule
• 0 or 129…255 = No schedule
Schedulex.SequenceNumber SINT Indicates that the schedule information is valid and that
this schedule should be processed.
All values.
Schedulex.OutputPointSelect SINT Selects the output point that this schedule applies to. 0xFF
means no output point selected.
0…15
Schedulex.Data BOOL Output data to be applied at time that is specified in
schedule.
0 or 1
Schedulex.TimeOffset DINT Offset from schedule base time. Used for scheduled output
consumed tags. Base/Offset scheme that is used to fit
enough schedules in the assembly.
All values.
