Rockwell Automation Allen-Bradley FLEX 5000 User Manual

Rockwell Automation Publication 5094-UM001C-EN-P - April 2019 153
Module Tag Definitions Appendix B
Safety Output Tags
Tabl e 39 describes the 5094-OB16S module safety output tags.
5094-OW8I Module Tags
This section describes the tags that are associated with the 5094-OW8I module.
Configuration Tags
Tabl e 40 describes the 5094-OW8I module configuration tags.
Table 39 - 5094-OB16S Module Safety Output Tags
Name Data Type Definition Valid Values
Ptxx.Data BOOL Current digital output value. • 0 = Off
•1 = On
Ptxx.ResetFault BOOL When ‘Latch Fault until reset via output tag’ mode is Enabled,
the I/O channel will hold safety output fault indications until
it checks that the fault is removed. If the fault is removed, it
will clear
only the fault status upon detecting that the
ResetFault bit in its channel sees a rising edge.
• Rising edge: the fault status is released
if the fault has been removed.
STATUS
POWER
DIGITAL 16 INPUT 24 VDC
5094-IB16
1
1
TB3
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Standard Modules
Table 40 - 5094-OW8I Module Configuration Tags
Name Data Type Definition Valid Values
Ptxx.FaultMode BOOL Selects the behavior the output point takes if a
communication fault occurs. FaultValue defines the value
to go to when set to user-defined value.
• 0 = Go to a user-defined value
• 1= Hold last state
Ptxx.FaultValue BOOL Defines the value that the discrete output should assume
if a communication fault occurs when FaultMode = 0.
•0 = Off
•1 = On
Ptxx.ProgMode BOOL Selects the behavior the output point should take when
transitioned into Program mode. ProgValue defines the
value to go to when set to user-defined value.
• 0 = Go to a user-defined value
• 1= Hold last state
Ptxx.ProgValue BOOL Defines the value that the output should take when the
connection transitions to Program mode if the ProgMode
bit is set to "User-Defined Value".
• 0 = The output state is Off during Program
mode.
• 1 = The output state is On during Program
mode.
Ptxx.FaultFinalState BOOL If FaultValueStateDuration is nonzero determines the final
Output state after the configured FaultValueStateDuration
time out occurs.
• 0 = The output state is Off after the
FaultValueStateDuration time expires.
• 1 = The output state is On after the
FaultValueStateDuration time expires.
Ptxx.ProgramToFaultEn BOOL Determines if an output should transition to the Fault
Mode if the connection faults while in Program Mode.
• 0 = Stay in Program Mode
• 1 = Go to Fault mode
Ptxx.FaultValueStateDuration SINT This value determines the length of time the Fault Mode
state is held before the FaultFinalState being applied.
•0 = Hold forever (default).
• 1, 2, 5, or 10 seconds
