Rockwell Automation Publication 5094-UM001C-EN-P - April 2019 87
Chapter 6
Configure the Standard Module
This chapter describes how to configure your FLEX 5000™ digital I/O modules
in a Logix Designer application project. You can use the default module
configuration or edit the module configuration.
Topic Page
Before You Begin 88
Create a New Module 88
Edit the Module Configuration Common Categories 93
Edit 5094-IB16 Module Configuration Categories 97
Edit 5094-OB16 Module Configuration Categories 103
Edit 5094-OW8I Module Configuration Categories 104
View the Module Tags 105
IMPORTANT Consider the following:
• You must use the Studio 5000 Logix Designer® application, version 31 or
later, to configure the FLEX 5000 I/O modules. Version 31 or later is slightly
different from previous programming software versions. For example,
in some cases, instead of tabs across the top of the Module Properties
dialog box, the application uses categories on the left side of the
dialog box.
• This chapter does not explain the user-configurable module features that
you can edit on different screens in your Logix Designer application project.
For detailed information about module features, see the following:
- Chapter 2
, Common Digital I/O Module Features on page 45
- Chapter 3, Input Module Features on page 53
- Chapter 4, Output Module Features on page 57
STATUS
POWER
DIGITAL 16 INPUT 24 VDC
5094-IB16
1
1
TB3
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
