Rockwell Automation Publication 5094-UM001C-EN-P - April 2019 105
Configure the Standard Module Chapter 6
View the Module Tags
When you create a module, the Logix Designer application creates a set of tags
that you can view in the Tag Editor. Each configured feature on your module has
a distinct tag that is available for use in the controller program logic.
Complete the following steps to access the module tags.
1. In the Controller Organizer, right-click Controller Tags and choose
Monitor Tags.
The Controller Tags dialog box appears with data.
2. To view the tags, click the symbols as shown.
For more information on module tags, see Appendix B
, Module Tag Definitions
on page 137.
