Appendix B
Module Tag Definitions
Module tags are created when you add a module to the Logix Designer
application project.
The set of module tags associated with a module depends on the module type
and Module Definition choices made during module configuration. For example,
if you use a Listen Only Connection, the Logix Designer application creates only
Input tags for that module.
The following types of tags are available with FLEX 5000® I/O modules:
• Configuration
• Event Input - 5094-IB16 and 5094-IB16XT modules only
• Event Output - 5094-IB16 and 5094-IB16XT modules only
•Input
•Output
The tables contained in this section list all of the tags available with a module.
Not all tags in the list are used when that module type is added to a project. Tag
use varies by module configuration.
Topic Page
Tag Name Conventions 138
Access the Tags 138
5094-IB16 Module Tags 139
5094-IB16S and 5094-IB16SXT Module Tags 147
5094-OB16 Module Tags 149
5094-OB16S and 5094-OB16SXT Module Tags 152
