Rockwell Automation Publication 5094-UM001C-EN-P - April 2019 147
Module Tag Definitions Appendix B
5094-IB16S and
5094-IB16SXT Module Tags
This section describes the tags that are associated with the 5094-IB16S and
5094-IB16SXT modules.
Input Tags
Tabl e 32 describes the 5094-IB16S and 5094-IB16SXT module input tags.
STATUS
POWER
SAFETY DIGITAL 16 INPUT 24 VDC
5094-IB16S
5
5
TB3I
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Table 32 - 5094-IB16S Module Safety Input Tags
Name Data Type Definition Valid Values
RunMode BOOL Module’s operating state • 0 = Idle
•1 = Run
ConnectionFaulted BOOL Indicates if a connection is running.
The module sets this tag to 0 when connected. If the
module is not connected, it changes the tag to 1.
• 0 = Connection running
• 1 = Connection not running
DiagnosticActive BOOL Indicates if any diagnostics are active or if the prognostics
threshold is reached.
•0 = No diagnostics active
• 1 = One or more diagnostics are active or the
prognostics threshold is reached
DiagnosticSequenceCount SINT Increments for each time a distinct diagnostic condition is
detected, and when a distinct diagnostic condition
transitions from detected to not detected.
Set to zero by product reset or power cycle. Wraps from
255 (-1) to 1 skipping zero.
•1…255
The value of 0 is skipped except during module
power-up.
Ptxx.Data BOOL Indicates the current safety input value. • 0 = Off
•1 = On
Ptxx.Fault BOOL • Indicates that channel data is inaccurate and
cannot
be trusted
for use in the application.
For more information, see Module Data Quality
Reporting on page 47.
• The channel is set to Not Used.
• 0 = Good data
• 1 = Bad data (faulted) or set to Not Used
– If the tag is set to 1, you must troubleshoot
the module to correct the cause of the
inaccuracy.
IMPORTANT: Once the condition that
causes the tag to change to 1 is removed,
you must complete the steps described in
Safety Input Fault Reset
on page 76 to reset
this tag to 0.
– If the tag is 1 because the channel is set to
Not Used, no action is required.
Ptxx.Uncertain BOOL Indicates that the channel data can be inaccurate but the
degree of inaccuracy is not known.
For more information, see Module Data Quality Reporting
on page 47.
• 0 = Good data
•1 = Uncertain data
This tag is set to 1 when the module has
reached a critical operating temperature or is
higher the acceptable operating temperature.
IMPORTANT: Once the condition that causes
the tag to change to 1 is removed, the tag
automatically resets to 0.
Ptxx.ShortCircuit BOOL Indicates a short circuit. • 0 = No short circuit
•1 = Short circuit
Ptxx.Status BOOL Indicates the status of the channel. • 0 = Bad, causing a fault
•1 = Good
