Output Module Features Chapter 4
Feature Specific to Only
5094-OW8I and
5094-OW8IXT Modules
The following topic is specific to only the 5094-OW8I and 5094-OW8IXT
relay modules.
Isolated Output
These digital output modules provide point-to-point wiring isolation:
• 5094-OW8I
• 5094-OW8IXT
STATUS
POWER
DIGITAL 16 INPUT 24 VDC
5094-IB16
1
1
TB3
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Standard Modules
IMPORTANT Although some FLEX 5000 digital I/O modules do not provide wiring
isolation, all FLEX 5000 modules maintain internal electrical isolation
between the system-side and field-side power buses.
