58 Rockwell Automation Publication 5094-UM001C-EN-P - April 2019
Chapter 4 Output Module Features
Configurable Point-level Output State in Program Mode or
Fault Mode
You can configure individual output points to specific states when the module is
in Program mode or Fault mode. The following output states are available:
•Off
•On
Hold last state
To see where to configure the output states in Program mode or Fault mode, see
the following:
5094-OB16 and 5094-OB16XT modules - page 103
5094-OB16S and 5094-OB16SXT modules - page 117
5094-OW8I and 5094-OW8IXT modules - page 104
Connection Fault Handling
You can configure FLEX 5000 output module behavior when a connection fault
occurs, that is, the connection between the owner-controller and the output
module breaks.
You must de fi ne th e f o llow in g :
In standard and safety modules
Immediate output behavior when the connection breaks
In standard modules only
Length of time that the output behaves as defined
Output behavior if the connection remains broken when the length of
time that is defined previously expires
ATTENTION: Overriding Output state from OFF to ON/HOLD during
Program or Communication Fault modes will interfere with the safety state
of the point.
