Appendix A
Troubleshoot Your Module
FLEX 5000® I/O modules use the following status indicators:
• SA Power Indicator - This indicator operates the same for all FLEX 5000
I/O modules.
• Module Status Indicator - This indicator operates the same for all
FLEX 5000 I/O modules.
• I/O Status Indicator - This indicator operates differently based on the
module type.
Topic Page
SA Power Indicator 124
Module Status Indicator 125
FLEX 5000 Digital Input Modules Status Indicators 126
FLEX 5000 Output Modules Status Indicators 127
FLEX 5000 Safety Input Modules Status Indicators 129
FLEX 5000 Safety Output Modules Status Indicators 130
Use the Logix Designer Application for Troubleshooting 131
