Rockwell Automation Allen-Bradley Kinetix 3 2071-AP8 - Power Dissipation Specifications

Rockwell Automation Publication 2071-UM001E-EN-P - November 2013 21
Install the Kinetix 3 Drive System Chapter 2
Power Dissipation Specifications
Use this table to size an enclosure and calculate required ventilation for your
Kinetix 3 drive system
Drive Cat. No.
Usage as% of Rated Power Output
(watts)
20% 40% 60% 80% 100%
2071-AP0 19.29 20.0 20.6 21.3 22.0
2071-AP1 20.14 21.6 23.1 24.6 26.2
2071-AP2 21.70 24.6 27.6 30.6 33.7
2071-AP4 25.59 31.9 38.4 45.2 52.2
2071-AP8 26.36 32.3 38.6 45.1 52.0
2071-A10 30.87 40.2 50.1 60.6 71.5
2071-A15 37.37 50.1 63.8 78.4 94.0
