Chapter 2 Install the Kinetix 3 Drive System
Mount Your Kinetix 3 Drive
The procedures in this section assume you have prepared your panel and
understand how to bond your system. For installation instructions regarding
other equipment and accessories, refer to the instructions that came with each of
the accessories for their specific requirements.
Follow these steps to mount your Kinetix 3 drive.
1. Layout the position for the Kinetix 3 and accessories in the enclosure (refer
to Establishing Noise Zones
on page 26 for panel layout
recommendations).
Mounting hole dimensions for the Kinetix 3 are shown in Kinetix Servo
Drives Specifications Technical Data, publication GMC-TD003
.
2. Attach the Kinetix 3 drive to the cabinet, first by using the upper
mounting slots of the drive and then the lower.
The recommended mounting hardware is M4 (#6-32) steel machine screw
torqued to 1.1 N•m (9.8 lb•in). Observe bonding techniques as described
in Bonding Drives
on page 23.
3. Tighten all mounting fasteners.
ATTENTION: This drive contains electrostatic discharge (ESD) sensitive parts
and assemblies. You are required to follow static control precautions when you
install, test, service, or repair this assembly. If you do not follow ESD control
procedures, components can be damaged. If you are not familiar with static
control procedures, refer to Allen-Bradley publication 8000-4.5.2
, Guarding
Against Electrostatic Damage or any other applicable ESD Protection Handbook.
To improve the bond between the Kinetix 3 drive and subpanel, construct your
subpanel out of zinc plated (paint-free) steel.
