50 Rockwell Automation Publication 2071-UM001E-EN-P - November 2013
Chapter 3 Kinetix 3 Drive Connector Data
Serial Interface Connection
The IEEE-1394 connectors (Comm0A and Comm0B) are provided on the
Kinetix 3 drive.
This table provides the drive’s default serial port configuration. This
configuration is used for communication between a drive and personal computer
with Connected Component Workbench software.
Table 22 - USB Communication Specification
This table provides the drive’s default serial port configuration. This
configuration is used for communication between a drive and personal computer
with Ultraware software.
Table 23 - RS-232 Serial Communication Specifications
Attribute Value
Communication Protocol RS-485
Baud 192,000
Data bits 8
Parity None
Stop bit 1
Operator interface bit pattern 1102
Cabling Catalog numbers 2090-CCMUSDS with 1203-USB
Node address 248
Attribute Value
Communication Protocol RS-232
Baud 57,600
Data bits 8
Parity None
Stop bit 1
Operator interface bit pattern 0005
Cabling Catalog number 2090-CCMPCDS
