48 Rockwell Automation Publication 2071-UM001E-EN-P - November 2013
Chapter 3 Kinetix 3 Drive Connector Data
Analog Outputs
The Kinetix 3 drive contains two analog outputs (A.out) that can be configured
through Ultraware software to represent internal drive variables. These variables
can be assigned to an analog output:
Motor Feedback Position
Master Position
Follower Position
Position Error
Position Command Count Frequency
Velocity Command
Velocit y Feedback
Velocit y Error
Current Command
Current Feedback
U Phase Current
V Phase Current
W Phase Current
Commutation Angle
Mechanical Angle
Shunt Power Limit Ratio
Instantaneous Shunt Power
Drive Utilization
Absolute Rotations
Bus Voltage
Velocity Command Offset
Current Command Offset
Motor Temperature
Analog Command – Velocity
Analog Command – Current
Figure 22
shows the configuration of the analog outputs.
