Rockwell Automation Allen-Bradley Kinetix 3 2071-AP8 User Manual

Rockwell Automation Publication 2071-UM001E-EN-P - November 2013 51
Kinetix 3 Drive Connector Data Chapter 3
This table provides the configuration is used for communication between a drive
and programmable logic controller and drive-to-drive communication. You can
change the serial communication protocol by using front panel input keys.
Table 24 - RS-485 Serial Communication Specifications
Attribute Value
Communication Protocol RS-485
Baud 192,000
Data bits 8
Parity None
Stop bit 1
Operator interface bit pattern 1102
Cabling Catalog numbers 2090-CCMCNDS and 2090-CCMDSDS
