56 Rockwell Automation Publication 2071-UM001E-EN-P - November 2013
Chapter 4 Connect the Kinetix 3 Drive
Figure 25 - Three-phase Power Configuration (Delta secondary)
Feeder and branch short circuit protection is not illustrated.
L1
L2
L3
L1
L2
L3
E
L1
L2
L3
IPD
L1
L2
L3
L1C
L2C
Transformer (Delta) Secondary
Ground Grid or
Power Distribution Ground
Kinetix 3 Drive
Three-phase AC Input
Bonded Cabinet Ground Bus
AC Line
Filter
IPD Terminals
Corner Grounded
(optional)
