Rockwell Automation Allen-Bradley Kinetix 5500

192 Rockwell Automation Publication 2198-UM001M-EN-P - November 2022
Appendix A Interconnect Diagrams
Figure 105 - Kinetix 5500 Capacitor Module Block Diagram
RELAY+
RELAY-
24V+
24V-
DC-
DC+
1360 µF
DC Bus
Connector
24V Control Power
Module Status
Connector
(N.O. relay output)
Status Indicator
SMPS
Protection
Precharge
Capacitor Bank
Relay K1
Relay K2
Fuse F2
Chassis
