196 Rockwell Automation Publication 2198-UM001M-EN-P - November 2022
Appendix B Update the Drive Firmware
Update Firmware Follow these steps to select the drive module to update.
1. In the Logix Designer application, from the Tools menu, choose
ControlFLASH.
The Welcome to ControlFLASH dialog box appears.
2. Click Next.
The Catalog Number dialog box appears.
3. Select your drive module.
In this example, the 2198-H003-ERS servo drive is selected.
4. Click Next.
The Select Device to Update dialog box appears.
You can also open the ControlFLASH software by choosing Start >
Programs > FLASH Programming Tools > ControlFLASH.
