Chapter 1 Start
Catalog Number
Explanation
Kinetix 5500 drive catalog numbers and performance specifications.
Table 3 - Kinetix 5500 Servo Drive Catalog Numbers
Drive Cat. No.
(hardwired STO)
Drive Cat. No.
(integrated STO)
Frame Size Input Voltage
Continuous Output
Power
kW
Output Current
Continuous
A 0-pk
Peak
A 0-pk
2198-H003-ERS 2198-H003-ERS2
1
195…264V rms, single-phase
195…264V rms, three-phase
324…528V rms, three-phase
0.2 kW
0.3 kW
0.6 kW
1.4 3.5
2198-H008-ERS 2198-H008-ERS2
0.5 kW
0.8 kW
1.6 kW
3.5 8.8
2198-H015-ERS 2198-H015-ERS2
2
1.0 kW
1.5 KW
3.2 kW
7.1 17.7
2198-H025-ERS 2198-H025-ERS2
195…264V rms, three-phase
324…528V rms, three-phase
2.4 kW
5.1 kW
11.3 28.3
2198-H040-ERS 2198-H040-ERS2
4.0 kW
8.3 kW
18.4 45.9
2198-H070-ERS 2198-H070-ERS2 3
7.0 kW
14.6 kW
32.5 81.3
Table 4 - Capacitor Module Catalog Number
Capacitor Module
Cat. No.
Frame Size Rated Voltage Capacitance
2198-CAPMOD-1300 2 650V DC, nom 1360 µF, min
Table 5 - Shared-bus Connector Kit Catalog Numbers
Kit Cat. No. Frame Size Application Description
2198-H040-ADP-IN Frame 1 or 2 First drive
• Mains AC input wiring connector
• 24V DC input wiring connector
• DC bus T-connector
2198-H040-A-T
Next drive is…
Frame 1 drives:
2198-H003-ERSx
2198-H008-ERSx
Frame 2 drives:
2198-H015-ERSx
2198-H025-ERSx
2198-H040-ERSx
AC sharing only AC bus T-connector
2198-H040-D-T DC sharing only DC bus T-connector
2198-H040-P-T Control power sharing only Control power T-connector
2198-H040-AD-T AC and DC-bus sharing AC and DC bus T-connectors
2198-H040-AP-T AC and control power sharing AC and control power T-connectors
2198-H040-DP-T DC and control power sharing DC and control power T-connectors
2198-H040-ADP-T AC, DC, and control power sharing AC, DC, and control power T-connectors
2198-H070-ADP-IN
Frame 3 drive:
2198-H070-ERSx
First drive
• Mains AC input wiring connector
• 24V DC input wiring connector
• DC bus T-connector
2198-H070-A-T
Next drive is…
Frame 3 drives:
2198-H070-ERSx
AC sharing only AC bus T-connector
2198-H070-D-T DC sharing only DC bus T-connector
2198-H070-P-T Control power sharing only Control power T-connector
2198-H070-AD-T AC and DC-bus sharing AC and DC bus T-connectors
2198-H070-AP-T AC and control power sharing AC and control power T-connectors
2198-H070-DP-T DC and control power sharing DC and control power T-connectors
2198-H070-ADP-T AC, DC, and control power sharing AC, DC, and control power T-connectors
