Rockwell Automation Publication 2198-UM001M-EN-P - November 2022 57
Chapter 4
Connector Data and Feature Descriptions
This chapter illustrates drive connectors and indicators, including connector
pinouts, and provides descriptions for Kinetix® 5500 drive features.
Topic Page
Kinetix 5500 Connector Data 58
Understand Control Signal Specifications 62
Feedback Specifications 65
Safe Torque Off Safety Features 66
