6 | Startup
Page 28 of 104 CIRUS
®
UPT-6400 VERSION 1 | EN-US
Setting Menu number
Language 201 (Operation menu)
Reset to defaults 202 (Operation menu)
Temperature range and temperature
coefficient of the heating element
301, 302, 305 (Heating element menu)
3. If the heating element is cold, activate the AUTOCAL feature:
- Via the Settings menu, menu number 107 or
- via the AUTOCAL signal, terminals34+39
ð A counter in the screen shows the calibration process (approx. 10…15sec).
During this process, there is voltage of approx.0VDC at the actual value out-
put (terminals 17+18). If a temperature display is connected, it shows 0…3°C.
ð When zero calibration is completed, the standard display with an actual value
of 20°C appears on the screen. Voltage of 0.66VDC automatically sets at the
actual value output (at the 300°C range and with a AUTOCAL =20°C) or
0.4VDC (at the 500°C range). When a temperature display ATR-x is con-
nected, it is set to "Z".
ð If zero calibration is not performed correctly, an error message with the error
code 104, 105, 106 or 211 appears. The temperature controller is not config-
ured properly (Refer to section Temperature controller configuration [}28]
and to the application report).
Configure the temperature controller and then perform zero calibration again.
4. Set the desired sealing temperature in the Settings menu, menu number101,
or apply voltage of 0…10VDC to the analog input (terminals36+39).
ð If an external sealing temperature (analog input terminals36+39) and an inter-
nal sealing temperature (menu number101) are specified at the same time,
the higher temperature is used and shown in the standard screen.
5. Start heatup:
- Touch Manual (standard display) or
trigger the START signal (6+18).
ð The heatup and control process can be observed on the screen.
When the temperature rises steadily, the function is working properly.
If the temperature jumps around, fluctuates or briefly moves in the wrong di-
rection, this is an indication that the U
R
measuring line has been laid incor-
rectly. Refer to section Error messages [}84] for further information.
6. Adjust the correction factor to optimize the heatup and control process.
Refer to section Correction factor [}79] for further information.
ð The temperature controller is ready.
6.3 Temperature controller configuration
WARNING
Danger, supply voltage at device
Line voltage is being applied to the electrical connections on the device.
 Electrical installation may be performed only by qualified electricians.
 Switch off the current supply.
 Secure the current supply to prevent it from being switched on again.
Prerequisite
• The temperature controller is voltage-free.
