8.3.5 USB interface
!
USC
40 39 38 37 36 35 34 33
24
23
22 21
20 19
18
1
7
16
15
14
13
12
8
1
1
01
5
6
9
4 3 2 1
Ma
de in Germany
ropex-group.com
visual
®
ROPEX
AUX
1
Illustration18: USB interface
The temperature controller has a USB interface(1).
The USB-C interface enables a data connection to be set up to ROPEXvisual
®
, the
ROPEX visualization software.
The visualization software is used for system diagnostics and process visualization.
Downloads
Further information can be found in the operating instructions for the visualization soft-
ware ROPEXvisual
®
. The operating instructions and software can be found on the fol-
lowing website:
www.ropex-group.com/downloads
Menu path
Products > Downloads > ROPEXvisual
®
8.3.6 AUX interface
!
USC
40 39 38 37 36 35 34 33
24
23
22 21
20 19
18
1
7
16
15
14
13
12
8
1
1
01
5
6
9
4 3 2 1
Ma
de in Germany
ropex-group.com
visual
®
ROPEX
AUX
1
Illustration19: AUX interface on temperature controller
The temperature controller has an internal AUX interface(1).
The AUX interface is used for diagnostics and maintenance purposes.
