Table 2-1. Rosemount 2088 and 2090 with 4–20 mA HART Protocol Device Revisions and Files
Release date
Device identification
Device driver
identification
Review
instructions
Review
functionality
NAMUR
hardware
revision
(1)
1. NAMUR revision is located on the hardware tag of the device. Differences in level 3 changes, signified above by xx, represent minor product changes
as defined per NE53. Compatibility and functionality are preserved and product can be used interchangeability.
NAMUR
software
revision
(1)
HART
software
revision
(2)
2. HART software revision can be read using a HART capable configuration tool. Value shown is minimum revision that could correspond to NAMUR
revisions.
HART
universal
revision
Device
revision
(3)
3. Device driver file names use Device and DD revision, e.g. 10_01. HAR protocol is designed to enable legacy device driver revisions to continue to
communicate with new HART devices. To access new functionality, the new DD must be downloaded. It is recommended to download new DD files
to ensure full functionality.
Manual
document
number
Change
description
Aug-16 1.1.xx 1.0.xx 3
710
00809-0100-4108
(2088)
00809-0100-4690
(2090)
(4)
4. Updated electronics hardware design. Intrinsic Safety temperature classification change.
59
(5)
5. HART revision 5 and 7 selectable, LOI, configurable alarms, expanded engineering units.
Jan-13 N/A 1.0.xx 1
7 10
N/A5 9
Jan-98 N/A N/A 178 5 3
Table 2-2. Rosemount 2088 with 1–5 Vdc Low Power HART Protocol Device Revisions and Files
Release date
Device identification
Device driver
identification
Review
instructions
Review
functionality
NAMUR
hardware
revision
(1)
1. NAMUR revision is located on the hardware tag of the device. Differences in level 3 changes, signified above by xx, represent minor product changes
as defined per NE53. Compatibility and functionality are preserved and product can be used interchangeability.
NAMUR
software
revision
(1)
HART
software
revision
(2)
2. HART software revision can be read using a HART capable configuration tool. Value shown is minimum revision that could correspond to NAMUR
revisions.
HART
universal
revision
Device
revision
(3)
3. Device driver file names use Device and DD revision, e.g. 10_01. HART protocol is designed to enable legacy device driver revisions to continue to
communicate with new HART devices. To access new functionality, the new DD must be downloaded. It is recommended to download new DDfiles to
ensure full functionality.
Manual
document
number
Change
description
Jan-13 N/A 1.0.2 3
710
00809-0100-4108
(2088)
00809-0100-4690
(2090)
(4)
4. HART revision 5 and 7 selectable, LOI, configurable alarms, expanded engineering units.
59
Jan-98 N/A N/A 178 5 3 N/A
